Number of display digits: 4
Character height (measured value): 15.2 mm
Power supply: 100…240 VAC
Control modes: Cooling control, heating control
Control method: 2-PID control, ON-OFF control
Number of channels: 1
Temperature ranges
0…100ºC
0…120ºC
0…1300ºC
0…165ºC
0…1700ºC
0…1800ºC
0…2300ºC
0…260ºC
0…90ºC
-100…850ºC
-199.9…400ºC
-199.9…500ºC
-20…400ºC
-20…500ºC
-200…1300ºC
-200…400ºC
-200…850ºC
-200…600ºC
Number of sensor inputs: 1
Sensor input types
K, J, T, E, L, U, N, R, S, B, C, W, PL2, Pt100Ω, JPt100Ω, infrared temperature sensor, 0…20 mADC, 4…20 mADC, 0…10 VDC, 0…5 VDC, 1…5 VDC
Number of control outputs: 1
Control output type: Voltage output for driving SSR
Number of auxiliary outputs: 2
Auxiliary output type: Relay output
Communication: None
Mounting method: Flush mounting
Panel cutout dimensions: W45 × H45 mm
Connection type: Screw terminals
Ambient humidity (non-condensing): 25…85%, 90% max.
Approximate weight: 120 g
Overall width: 48 mm
Overall height: 48 mm
Overall depth: 64 mm
Protection rating: IP00, IP20, IP66
