Omron Electronics G9TA-U1AP DC12 z~~Latching Relay AC Latching Relay High Power switching

Width: 410000018.0000~~18 mm

Height: 410000034.5000~~34.5 mm

Length: 410000039.1000~~39.1 mm

Coil Type: z~~Latching

Unit Weight: 42 g

Coil Current: 410000083.0000~~83 mA

Coil Voltage: 510000012.0000~~12 VDC

Current Rating: 510000060.0000~~60 A

Mounting Style: z~~Through Hole

Coil Resistance: 510000145.0000~~145 Ohms

Coil Termination: z~~Solder Pin

Contact Material: z~~Silver (Ag)

Power Consumption: 510000001.0000~~1 W

Switching Voltage: 510000250.0000~~250 VAC

Relay Contact Form: 510000001.0000~~1 Form A (SPST-NO)

Contact Termination: z~~Solder Pin

Contact Current Rating: 510000060.0000~~60 A
