Width: 10.3 mm
Height: 15.8 mm
Length: 20.3 mm
Coil Type: Non-Latching
Unit Weight: 6.500 g
Coil Current: 33.3 mA
Coil Voltage: 12 VDC
Contact Form: SPDT (1 Form C)
Mounting Style: Through Hole
Coil Resistance: 360 Ohms
Coil Termination: Solder Pin
Contact Material: Silver Alloy (Ag)
Power Consumption: 400 mW
Switching Voltage: 277 VAC, 30 VDC
Relay Contact Form: 1 Form C (SPDT-NO, NC)
Contact Termination: Solder Pin
Contact Current Rating: 10 A
Maximum Switching Current: 5 A
