Omnitek U-VISC 220 Kinematic Viscometer (0.15 - 25,000 mm2/s)

Nr. of samples: 32

Nr. of baths: 2

Tubes / bath: 2

Each bath features a 32-position sampling tray (16 samples per tube)

Measuring range: 0.15 - 25,000 mm2/s @ 40ºC

Temperature range: 15 - 150ºC *

Temperature stability: 15°C to 100ºC: ± 0.01ºC *, Up to 150ºC: ± 0.03ºC

Timer accuracy: 0.001 s

Sample volume: 8 - 16 ml

Solvent consumption: 12 - 15 ml per cycle

Viscometer type: Ubbelohde based

Sensor type: Thermal / optical

* For temperatures around ambient, an external chiller is required
