OMEGA XBUT4YE 6.2 mm Width, Feedthrough Terminal Block, 600 Vac/30 A

Wire Gauge: N/A

Thread Type: Metric

Amperage, Max: 0 A

Color Options: Yellow

Terminal Width: 16 mm

Voltage Rating: N/A

Wire Size, Max: 4 mm²

Load Current, Max: 150 A

Tightening Torque: 28.3 to 32.7 Nm

Cross-Section Area: 50 mm²

V/A/AWG Compliance: Voltage Rating (UL-cUL Ratings)=600 V;Voltage Rating Connection Data=500 V;Amperage, Max (UL-cUL Ratings)=30 A;Wire Gauge (UL-cUL Ratings)=26 to 10 AWG;Wire Gauge Connection Data=26 to 10 AWG;Amperage, Max (Connection Data) = 16 A

Contamination Class: 3

Rated Surge Voltage: 8 kV

Compatible Wiring Note: Stranded Ferrule with Plastic Sleeve=1.5 - 35 mm²;Stranded with Ferrule=1.5 - 35 mm²;Stranded with Twin Ferrule with Plastic Sleeve=1.5 - 10 mm²;Solid=1.5 - 16 mm²

Insulation Strip Length: 9 mm
