OMEGA TAC80B-T Thermocouple to Analog Converter, Battery or AC Power (Thermocouple Type T, 1 mV/°C)

Width: 71 mm

Height: 57 mm

Accuracy: ± 1.6 °C

Input Type: Thermocouple Type T

Input Range: -20 to 300°C

Output Signal: Voltage

Number of Inputs: 1

Electrical Output: 1 mV/°C

Electrical Connection: Banana Plug

Cold Junction Compensation: 0.05°C/°C

Operating Temperature, Max: 300 °C

Operating Temperature, Min: -20 °C

Input Electrical Connection: Sub-D Female Miniature Connector
