OMEGA PSW-372 Industrial Pressure Switch for Harsh Environments with 2 Outputs (Gauge, 15 psi, NPT Female, 1/4 in, IP66, NEMA Type 4X)

Switch: Dual

Deadband: 2.5 to 5.9 inH2O

Materials: 316 Stainless Steel, Stainless Steel

Output Note: 15 A: 125/250/480 Vac, 0.5 A: 125 Vdc, 0.25 A: 250 Vdc

Sensor Type: Diaphragm

Switch Note: Two SPDT switches can be wired “normally open” or “normally closed”

Switch Type: SPDT NO/NC, Selectable

Output Value: 15A @ 125/250/480 Vac

Deadband Type: Fixed

Pressure Type: Gauge

Pressure, Max: 15 psi

Pressure, Min: 3 psi

Control Output: SPDT Relay

Proof Pressure: Up to 500 psi

Enclosure Ratings: IP66, NEMA Type 4X

Materials, Wetted: PTFE, Stainless Steel

Electrical Connection: 3/4 in NPSM with Screw Terminal block

Setpoint Repeatability: ± 1%

Process Connection Size: 1/4 in

Process Connection Type: NPT Female

Storage Temperature, Max: 66 °C

Storage Temperature, Min: -29 °C

Operating Temperature, Max: 66 °C

Operating Temperature, Min: -29 °C

Setpoint Repeatability Note: Typically shifts ± 1% of range per 28°C (50°F)
