OMEGA PSW-240D Industrial Hermetic Pressure Switch for Harsh Environments (Gauge, 1700 psi, NPT Female, 1/4 in, IP66, NEMA Type 4X)

Shock: Setpoint repeats after 15 g, 10 ms duration

Width: 4 in

Height: 8.4 in

Length: 2.3 in

Switch: Single

Weight: 6 lb

Deadband: 3.6 to 3.6 inH2O

Approvals: UL listed

Materials: Stainless Steel, Aluminum, Epoxy, NBR, Nitrile Rubber

Vibration: Setpoint repeats after 2.5 g, 5 to 500 Hz

Output Note: 11 A 125/250 Vac resistive

Sensor Type: Diaphragm

Switch Note: Switch Output: Hermetically sealed SPDT or DPDT switch can be wired “normally open” or “normally closed”

Switch Type: DPDT

Weight Note: 0.7 to 2.7 kg (1.5 to 6 lb) (varies by model)

Output Value: 11A @ 125/250/480 Vac

Deadband Type: Fixed

Pressure Type: Gauge

Pressure, Max: 1700 psi

Pressure, Min: 100 psi

Control Output: DPDT Relay

Proof Pressure: Up to 2500 psi

Enclosure Ratings: IP66, NEMA Type 4X

Electrical Connection: Screw Terminal

Setpoint Repeatability: ± 1%

Process Connection Size: 1/4 in

Process Connection Type: NPT Female

Process Temperature, Max: 93 °C

Process Temperature, Min: -23 °C

Storage Temperature, Max: 71 °C

Storage Temperature, Min: -54 °C

Operating Temperature Note: setpoint typically shifts less than 1% of range for a 28°C (50°F) ambient temperature change

Operating Temperature, Max: 71 °C

Operating Temperature, Min: -18 °C
