OMEGA OS1327D -35 °C to 500 °C Infrared Thermocouple Thermometer (Max, Min, 60:1, 500 °C)

Alarm: High and Low

Laser: Single Laser

Width: 118 mm

Height: 172 mm

Length: 46 mm

Memory: 21000 set Auto Data, 99 set Manual Data

Weight: 220 g

Accuracy: ± 2 °C (± 3.6 °F)

Resolution: 1.1°C

Form factor: Pistol Grip

Laser Power: <1 mW

Applications: Air and HVAC, Automotive, Building and Maintenance, Industrial and Manufacturing, Laboratories and Scientific

Battery life: Up to 100 hr

Display Type: LCD

Accuracy Note: ± 2% reading or ± 2ºC

Field of view: 60:1

Response Time: 2 sec

Emissivity, Max: 1

Emissivity, Min: 0.17

Field of View Note: 12:1 optics ratio with a 1" min target

Battery Size and Type: Alkaline 9V

Spectral Response, Max: 14 µm

Process Temperature, Max: 500 °C

Process Temperature, Min: -35 °C

Storage Temperature, Max: 60 °C

Storage Temperature, Min: -10 °C

Operating Temperature, Max: 50 °C

Operating Temperature, Min: 0 °C

Ancillary Temperature Probe: 150 to 1350 °C, Accuracy: ± 0.2%,Resolution: 0.1ºC

Display Monitoring Function: Max, Min

Datasheet
