OMEGA LC107-2 High Accuracy, Miniature, S-Beam Load Cells (2 lbF)

Width: 0.67 in

Height: 0.75 in

Length: 0.27 in

Linearity: ± 0.1%

Materials: Stainless Steel, Aluminum

Force Type: Compression, Tension

Hysteresis: ± 0.1%

Cable Length: 5 ft

Overload, Max: 300% FS

Repeatability: ± 0.05%

Safe Overload: 150% FS

Load Cell Type: S-beam

Supply Voltage: 5 Vdc

Electrical Output: 2 mV/V

Enclosure Ratings: IP40

Supply Power Note: 5 Vdc Nominal, 15 Vdc Maximum to 5 Vdc Nominal, 12 Vdc Maximum

Calibration Option: 5 POINT NIST

Load Cell Capacity: 2 lbF

Zero/Balance Error: ± 1%

5-Point Calibration: 0%, 50%, 100%, 50%, 0%

Thermal Span Effect: ± 0.009% FSO/°C

Thermal Zero Effect: ± 0.009% FSO/°C

Electrical Connection: Cable

Process Temperature, Max: 71 °C

Process Temperature, Min: 15 °C

Operating Temperature, Max: 93 °C

Operating Temperature, Min: -40 °C
