Measurement Range (Humidity): 0 to 100% RH @ 0 to 50°C (32 to 122°F)
Accuracy (25°C): ±2.5% RH
Long-Term Stability: Better than 1% RH per year (typical)
Temperature Compensation: 0.008% RH/°C (effect @ 05 RH)
Response: <15 seconds (90% @ 25°C in moving air at 0.5 m/sec)
Sensors:
Humidity: Thin-film capacitor
Output: Voltage: 0~1 Vdc
Supply Voltage: 12 to 40 Vdc (24 Vdc recommended)
Sensor Protection: Sintered filter
Housing: ABS plastic watertight enclosure to NEMA 4 (IP65)
Connections: Liquid-tight nylon, cable bushing fits 5 to 10 mm dia. (0.2 to 0.4”) cables
Operating Temperature: 0 to 50°C (32 to 122°F)
Weight: Approx 150 g (5.3 oz)
Comes complete with operator’s manual.
