OMEGA HH520 4-channel handheld data logger thermometer (-200 to 1372 °C, Types J,KT,E)

Specifications

Measurement Range:

J: -200 to 1000°C (-328 to 1832°F)

K: -200 to 1372°C (-328 to 2501°F)

T: -200 to 400°C (-328 to 752°F)

E: -200 to 750°C (-328 to 1382°F)

Accuracy (Does Not Include

Thermocouple Sensor Error): ±(0.1% rdg + 0.7°C)/±(0.1% rdg + 1.4°F) between 18 to 28°C (64 to 82°F); ±(0.4% rdg + 0.7°C)/±(0.4% rdg + 1.4°F) below -100°C (-148°F)

Resolution:

0.1°C <600°C (0.1°F <1000°F);

1.0°C ≥ 600°C (1.0°F ≥ 1000°F)

Temperature Coefficient: 0.01% of reading + 0.05°C per °C(<18 or >28°C)

Input Protection: 30 Vrms max

Sample Rate: 2 samples/sec

Power: Four 1.5 V “AAA” batteries (included); external power through USB interface

Battery Life: 100 hrs approx (alkaline batteries)

Operating Environment: 0 to 50°C (32 to 122°F); 10 to 90% RH non-condensing

Storage Environment: -20 to 60°C (-4 to 140 °F); 10 to 75% RH

Dimensions: 187 H x 75 W x 29 mm D (7.36 x 2.95 x 1.14")

Weight: 290 g (10.2 oz)

Software: Windows® XP/Vista/7/8/10

Datasheet
