OMEGA FTB335D Low Flow Indicating Paddlewheel Flow Meter (± 6 %, 93 °C, 5 l/min, 3/8 in, Barbed Fitting, 120 Vac)

Weight: 0.45 kg

Accuracy: ± 6 %

K-Factor: N/A

Approvals: RoHS

Cable Type: 3 Conductor Wire Shielded Cable

Cable Length: 6 ft

Display Type: LCD

Output Detail: Alarm Output: Open Collector 30 Vdc Maximum

Pressure Type: Gauge

Supply Voltage: 120 Vac

Electrical Output: Open Collector Alarm

Enclosure Ratings: IP56, NEMA Type 4X

Materials, Wetted: FKM, Polypropylene, PVC

Media Compatibility: Oil, Solvents, Water

Operating Pressure Note: PVDF Lens 150 psig (10 bar) @ 21°C (70°F)

Operating Pressure, Max: 150 psi

Operating Pressure, Min: 0 psi

Process Connection Size: 3/8 in

Process Connection Type: Barbed Fitting

Process Temperature Note: PVDF Lens tubing connectors: 93°C (200°F) at 0 psi

Process Temperature, Max: 93 °C

Volumetric Flow Rate, Max: 5 l/min

Volumetric Flow Rate, Min: 0.5 l/min
