Oceanus OC-300 Laser Dust Particle Detector

Light source: Laser diode(>100,000 hours MTBF)

Sensor: Ultra high sensitivity optical sensor

Particle size: 0.5um, 1.0um, 2.5um, 10um

Measuring range: 0-9999ug/m3 and 0-99999999PC/L

Resolution: 1ug/m3 and 1PC/L

Gas detection: With 1~3 gas type (Optional)

Tem/Humidity inspection Temperature: -40 ～ 120℃ ，

Humidity: 0-100%RH

Verification standard: According to GB/T16292-1996 and ISO14644-1

Flow Rate: 2.83 L /min (0.1cfm)

Sample time: 30s

Measuring mode: Quantity mode (unit of PC/L) and quality mode (unit of ug/m3)

Detect methods: Time detecting or circle detection is adjustable

Interface: RS232-USB

Data Storage function: Real-time storage or timing storage is adjustable; Storage capacity of 100000 group data, can check the history data on the counter screen

Print mode: Optional micro-printer, can reset the print period and print mode

Working environment: 5 ～ 45℃, ≤90%RH, non-condensing

Power supply: 4000mA rechargeable lithium battery

Explosion-Proof grade: ExiaⅡ CT4

Protection grade: IP65

Body material: ABS+PC

Size and Weight: 220*85*55 mm (LxWxD), 0.5kg (net weight)

Accessory: Box, data cable, Charger, CD
