NXP MCF5207CVM166 Microprocessors - MPU MCF5207 MINIME

Core: ColdFire V2

I/O Voltage: 3.3 V

Memory Type: DDR SDRAM, SDR SDRAM, SRAM

Unit Weight: 443.700 mg

Data RAM Size: 16 kB

Data Bus Width: 32 bit

Interface Type: I2C, SPI, UART

Mounting Style: SMD/SMT

Number of I/Os: 30 I/O

Number of Cores: 1 Core

Watchdog Timers: Watchdog Timer

Processor Series: ColdFire RISC Microprocessor

Moisture Sensitive: Yes

L1 Cache Data Memory: 8 kB

Maximum Clock Frequency: 166.67 MHz

Operating Supply Voltage: 1.4 V to 1.6 V

Number of Timers/Counters: 4 x 32 bit

L1 Cache Instruction Memory: 8 kB

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
