Nordson MiniBlue II Hot melt dispensing applicators (1,500 psi)
Operating Temperature:205° C (400° F) maximum
Operating Air Pressure:3.4 to 5.5 bar (50 to 80 psi)
Working Hydraulic Pressure:103 bar (1500 psi) maximum
Nozzles Standard:Saturn, single orifice (controlled engagements)
Nozzles MiniBlue II SureBead Orifice Sizes:.008, .012, .016, .020, .032, .040
Saturn Solenoid Valves:24 VDC, high-temperature, factory-installed
Electrical Service:240 VAC, 50/60 Hz; 200 VAC, 50/60 Hz optional
Maximum Cycle Rate:8000/min
Minimum Bead Deposition:2ms (adhesive dependent)
Adhesive Viscosity Range:500 to 1500 cps optimal; 500 to >5000 cps capability
