NGI N38336-500-240 Wide Range High Power Programmable DC Power Supply (36kW/500V/240A, 6U)

Voltage up to 2250V, current up to 5100A, power up to 180kW

Supporting master/slave parallel, extended power up to 1.8MW

Voltage accuracy 0.05%F.S., current accuracy 0.1%F.S.

Voltage and current sampling rate 500kHz, resolution 16 bits

Power factor 0.99, efficiency up to 93%

LAN port and RS232 interface as standard, GPIB, CAN, RS485 and USB as optional

CC&CV priority function

CC, CV and CP mode

Standard 19-inch 3U chassis

Editable rise and fall slew rate for voltage and current

Internal resistance simulation, SEQ function, voltage RAMP function

Multiple protections: OCP, OVP, LVP, OTP, OPP

Equipped with LCD screen, numeric buttons and knob to support local operation

Equipped with high-voltage isolation digital & analog, and monitoring interfaces

*For detailed specifications, please refer to the Datasheet.
