NF WF1968 Multifunction Generator (2CH; 0.01 μHz to 200 MHz)

Oscillation frequency: 0.01μHz to 200 MHz

Number of Channels: 2

Vertical resolution for waveform: 16 bits

Frequency setting resolution: 0.01 μHz (WF1967 / WF1968: 0.1 μHz at 50 MHz or greater)

Rising / falling variable: Pulse: 4.21 ns to 58.8 Ms

Arbitrary waveform data length / number of waves: 4 Ki to 1 Mi words / 128 waves, 4 Mi words

Maximum output voltage / resolution: 20 Vp-p / open, 10 Vp-p / 50 Ω (WF1967 / WF1968: amplitude ±2 V / open when exceeding 110 MHz)　Resolution: 0.1 mVp-p or 1 mVp-p (depending on conditions)

Power supply : 90 V to 250 V AC

Power consumption : 85 VA or less

External dimensions (mm): 216 (W) × 132.5 (H) × 332 (D)

Weight : approx. 3.0 kg
