NF 3625 Dual Channel Programmable Filter (0.01Hz to 159.9kHz, LP/HP/BP/BE, 48dB/oct, 2CH)

Cutoff frequency: 0.01Hz to 159.9kHz

No. of channels: 2

Roll off: 48dB/oct

Filter mode: LP-MF, LP-PL, HPF, BPF, BEF, THRU (MF: maximum flat, PL: phase linear)

Operational modes: SEPARATE (separate CH-A and CH-B), CASCADE (serially connected CH-A and CH-B)

Pass band gain: X1, X2, X5 selectable at both input and output

Input type: Single-ended or floating, selectable

Frequency response in THRU mode *: DC to 1MHz (+5dB, -3dB) typ.

Input impedance: 1MΩ ± 2%

Maximum attenuation: 100dB or greater (to 100kHz), 80dB or greater (to 1MHz)

GPIB: Standard

Power requirements: AC100, 120, 220 or 240V± 10% (max. 250V), switchable

Dimensions (mm): 434(W) X 132.5(H) X 400(D)

Weight: Approx. 10.5kg

* input and output gains : X 1, input voltage : 1Vrms
