Murata Power Solutions 60B684C High Power Inductor 680 UH 15%
Model60B684C
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 27 mm
Height: 20 mm
Length: 23.5 mm
Core Type: Wirewound
Shielding: Unshielded
Tolerance: 15 %
Inductance: 680 uH
Application: High Current
Termination: Standard
Unit Weight: 37 g
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 3 A
Maximum DC Resistance: 135 mOhms
Self Resonant Frequency: 1.59 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
