Murata Power Solutions 60B224C High Power Inductor 220 UH 15%
Model60B224C
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 27 mm
Height: 20 mm
Length: 23.5 mm
Core Type: Wirewound
Shielding: Unshielded
Tolerance: 15 %
Inductance: 220 uH
Application: High Current
Termination: Standard
Unit Weight: 37 g
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 5 A
Maximum DC Resistance: 50 mOhms
Self Resonant Frequency: 3.21 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
