Drilling / Tapping capacity:
- Mild steel: 25 mm / M20
- Cast iron: 30 mm / M24
Boring capacity:
- Mild steel: 80 mm
- Cast iron: 100 mm
Drilling depth: 180 mm
Cutting feedrate: 10~3000 mm/min
Spindle taper: MT#4
Spindle motor: AC servo motor 2.0 kw
Table size: 800 x 800 mm
Spindle nose to table surface top: 270~640 mm
Net weight: 1000 kgs
