Drilling /face mill / end mill cap. ( steel ): 25/76/20 mm
Tapping cap. ( optional ): 16 mm
Longitudinal travel: 380 mm
Cross travel: 150 mm
Spindle stroke: 95 mm
Column diameter: Ø92 mm
Table size: 585 x 190 mm
T-slot ( width x no. x pitch ): 14 x 4 x 24 mm
Spindle speed: 110~2580 rpm (12 steps)
Spindle speed ( optional ): -
Spindle taper: MT#3 or R8
Spindle motor: 3/4 HP
Net weight: 160 kgs
Datasheet
