Monolithic Power Systems (MPS) MPQ4262GQVE-0000-AEC1-P Switching Voltage Regulators 36V, 100W Buck-Boost Converter with Integrated Low-Side MOSFETS and an I 2C Interface for Automotive, AEC-Q100

Shutdown: Shutdown

Topology: Buck-Boost

Input Voltage: 3.6 V to 36 V

Mounting Style: SMD/SMT

Output Current: 5 A

Output Voltage: 1 V to 36 V

Development Kit: EVQ4262-QVE-00A

Load Regulation: 2 %

Number of Outputs: 1 Output

Quiescent Current: 775 uA

Input Voltage - Max: 36 V

Input Voltage - Min: 3.6 V

Switching Frequency: 580 kHz

Operating Supply Current: 1 uA

Maximum Operating Temperature: + 150 C

Minimum Operating Temperature: - 40 C
