Molex 85732-1008 Magnetic Jack Modular Conn/Ethernet Conn GIG PoE+ ENBL

Color: Black

Pitch: 1.27 mm, 2.54 mm

Gender: Jack (Female)

Shielding: Shielded, EMI Fingers

USOC Codes: RJ45

Application: 10/100/1000 Base-T PoE+

Unit Weight: 76 g

REACH - SVHC: Details

Configuration: 2x6

Tab Direction: Tab Up and Tab Down

Current Rating: 1 A

Mounting Angle: Right Angle

Mounting Style: Through Hole

Voltage Rating: 57 V

Contact Plating: Gold

LED L / R Color: Green, Yellow / Green, Yellow

Number of Ports: 12 Port

Contact Material: Copper Alloy

Termination Style: Solder

Mounting Direction: Side

Flammability Rating: UL 94 V-0

Number of Positions: 8 Position

Performance Category: Cat 5, Cat 5e

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: 0 C

Number of Positions / Contacts per Port: 8P8C
