Molex 53426-9111 Mini-Lock PCB Header PCB Header Single Row RA Thru Hole Tin Plating Pos Lock 11 Ckts GloWire Blk

Pitch: 2.5 mm (0.098 in)

Application: Wire-to-Board, Signal

Housing Color: Black

Contact Gender: Pin (Male)

Current Rating: 3 A

Mounting Angle: Right Angle

Mounting Style: Through Hole

Number of Rows: 1 Row

Voltage Rating: 250 VAC/DC

Contact Plating: Tin

Contact Material: Phosphor Bronze

Housing Material: Polyamide (PA)

Termination Style: Solder Pin

Mating Post Length: 4 mm (0.157 in)

Number of Positions: 11 Position

Insulation Resistance: 1 GOhms

Termination Post Length: 3.4 mm (0.134 in)

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 55 C
