Molex 19418-0040 Receptacle RECPT 16P 22-18 AWG dual row

Color: Black

Pitch: 5.84 mm (0.23 in)

Gender: Receptacle (Female)

Features: Without Connector Position Assurance

Application: Power, Wire to Board

Unit Weight: 36.597 g

Contact Gender: Without Socket Contacts

Current Rating: 18 A

Mounting Angle: Straight

Mounting Style: Cable Mount / Free Hanging

Number of Rows: 2 Row

Wire Gauge Max: 18 AWG

Wire Gauge Min: 22 AWG

Housing Material: Polymer

Wire Gauge Range: 22 AWG to 18 AWG

Termination Style: Crimp

Flammability Rating: UL 94 V-0

Number of Positions: 16 Position

Description/Function: MX150L Circuit Receptacle

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
