MKS CM 330 Compact, Air-cooled Microwave Power Supply (1kW; 2.45GHz Magnetron)

Power Output: 1400W

Power Requirements: 160 - 260 VAC

Line Frequency: 50/60 Hz

Output Current: 340 mA

Dimensions: 180 x 105 x 320 mm (7.1 x 4.1 x 12.6 inches) (WxHxD)

Weight: 3.8 kg (8.4 lbs.)

Cooling: Forced air, 80 m3/h

Ambient Operating Temperature: 40° C (104° F) maximum

Compliance: CE mark, Directive EMC and LV, through norms, EN61010-1, EN61000-6-4, EN61000-6-2

Preferred Microwave Magnetron Head: TxA10 (Open frame head, waveguide size WR340)

Compatible with: 1kW, 2.45 GHz Magnetron
