MKS 91150V Calibrated Reference Cell

Autoranging: Swithces to higher display range above 1.95 Sun, lower range below 1.90 Sun

Resolution: Irradiance: 0.0001 Sun @ 0-1.9500 Sun (low display range), 0.001 Sun @ 1.900-3.500 Sun (high display range)

Temperature: 0.01 °C

Sampling Rate: 2 readings/sec

Settling Time: within 1 sec for <0.25% (= 6τ)

RangeIrradiance: 0-3.500 Sun

Temperature: 0-199.9 °C capable

Operating Temperature Range: 10-40 °C

Operating Humidity: 0-90% relative humidity, non-condensing

Electrical Interface: Type K connector for thermocouple integrated beneath the PV reference cell

Amphenol T 3302 009 4-pin connector for reference cell 4-wire interface

Analog output BNC jacks for Sun and temperature output

Dimensions: Meter: 151 x 95 x 178 mm

Reference cell: 70 x 16 x 92 mm

Weight: 1.8 kg (meter)
