MKS 728A Heated General Purpose Absolute Baratron® Capacitance Manometers (10Torr; 8 VCR-F; 9-pin D-sub)

Sensor Type:Capacitance Manometer

Measurement Type:Absolute

Full Scale Range:10 Torr

Sensor Temperature:100°C

Fitting Type:8 VCR female

Analog Output:0 - 10 VDC

Electrical Connector:9-pin D-sub

Accuracy:0.50% of Reading

Response Time:<75 msec

Zero Temperature Coefficient:0.010% of Full Scale/°C

Span Temperature Coefficient:0.040% of Full Scale/°C

Operating Temperature Range:15 - 50°C

Overpressure Limit:45 psia or 2 x Full Scale range, whichever is greater

Burst Pressure:10 x Full Scale range or 90 psi, whichever is greater

Exposed Materials:Inconel®

Power Requirements: ± 15 VDC

For specific range please check the attachment below!
