Specifications:
Full Scale Pressure Ranges: 1, 2, 10, 100, and 1000 Torr (mmHg); 100, 200, 300, 400, and 500 psia
Accuracy: (includes non-linearity, hysteresis, and non-repeatability): ± 0.50% of Reading
Temperature Coefficients:
Zero: 0.020% Full Scale/°C
Span: 0.040% Reading/°C
Operating Temperature Range: 0° to 50°C (32° to 125°F)
Materials Exposed to Process Gases: Inconel, Type 316L stainless steel, and Type 304 stainless steel
Volume (Px side): 7.0 cm3
Overpressure Limit: 120% of FS, or 35 psia (240 kPa) – whichever is greater
Power Required/Output Signal: +24 to 32VDC into 500Ω load; two-wire 4-20 mA out. Output signal is 4.0 mA at 0 Torr and 20.0 mA at FS range
Fitting: ¼'' x 18 NPT
Compliance: NEMA 4, FM17US0326
Zero Adjustment: Continuously adjustable externally
Time Response: With snubber: 250 msec. Without snubber: 20 msec.
(FM Approval voided without snubber)
Mounting Position: Panel mount or pipe mount with U-bolt, process connection down
Housing Materials: 356-T6 aluminum (NEMA 4); 2-part polyurethane paint
Electrical Connection: ½” conduit with screw terminals
Weight: 6 lbs (3 kg)
For specific range please check the attachment below!
