Range:5-1010mm
Graduation: 0.001 mm
Block step: 10 mm straight
Feed error: ±1.5 µm
Inch-Metric: Metric
Retrace error: 1.5 µm
Micrometer adjustment: 20 mm
Micrometer feed: 0.5 mm
Block pitch accuracy:
Range ≤ 310 mm: ±1.5 μm
310 < range ≤ 610 mm: ±2.5 μm
610 < range ≤ 1010 mm: ±3.5 μm
Parallelism of blocks:
Range ≤ 610 mm: 1.5 μm
610 < range ≤ 1010 mm: 2 μm
Mass: 63.5 kg
