Mikrometry ETTB100 Torque Meter (5~100/0.01 N.m)

Capacity/Resolution: 5~100/0.01 N.m; 500~10000/1 N.cm; 50~1000/0.1 kgf.cm; 3.7~74/0.01 lbf.ft; 44~885/0.1 lbf.in;

Range: 5%~100% Capacity

Accuracy: ± 0.3% Readings

Selectable Units: N.m、N.cm、kgf.cm、lbf.ft、lbf.in

Display: 240*160 dot matrix LCD(3.1 inch) with LED Backlight

Overload Capacity: 120% of F.S.

Measurement Mode: Track, Peak, First Peak、Auto Peak、Auto First Peak、Double Peak

Display Mode: Digital / Curve

Data Sampling Rate: Up to 2KHz

Memory: 1000 data

SetPoint: Programmable high and low limits

Battery Indicator: The display flashes the battery icon when the battery is low

Power: 3.6VDC 1600mAH Ni-Mh rechargeable batteries

Battery Life: Approx. 25 hours per charge

Charger / Adaptor: Universal USB/BM charger, Input:110~240VAC

Temperature Effects: <0.03% FS per °C

Communication: USB or RS-232

Software: Free software for USB communication

Outputs: RS-232, "Within" set point output， "Under or over" set point output

Operating environment: Temperature: -10 to 40°C; Relative Humidity: 20 to 80%

Storage environment: Temperature: -20 to +50°C; Relative Humidity: 5 to 90%

Dimension: 197X183X83 mm

Weight: ~ 1.6 kg
