Microtips Technology REC001602ABPP5N00000 OLED Displays Blue OLED 16x2 Char Display

Width: 80 mm

Height: 36 mm

Thickness: 10 mm

Brightness: 80 cd/m2

Touch Panel: Without Touch Panel

Display Type: 16x2 Character Display

Viewing Angle: 160 deg

Mounting Style: Screw Mount

Illumination Color: Blue

Pixel Size - W x H: 0.55 x 0.65 mm

Viewing Area - W x H: 66 mm x 16 mm

Character Count x Line: 16 x 2

Module Size - W x H x T: 80 mm x 36 mm x 10 mm

Operating Supply Current: 30 mA

Operating Supply Voltage: 5 V

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 40 C
