Microrad 30B Magnetic Field Probe for NHT310F & NHT3DL (B Field, 1 Hz ÷ 400 kHz)

Compatibility: NHT310F and NHT3DL meters

TECHNICAL SPECIFICATIONS

Frequency range: 1 Hz ÷ 400 kHz

Type of frequency response: Flat

Measurement range: 300 nT ÷ 16 mT

Dynamic range: 94 dB

Sensor type: Coils

Directivity: Isotropic

Frequency response:

± 0.5 dB (50 Hz ÷ 50 kHz) @ 30µT

± 1 dB (50 kHz ÷ 400 kHz) @ 30µT

Linearity :

± 0.5 dB (0.1 μT ÷ 1 mT)

± 0.7 dB (1 mT ÷ 16 mT)

Isotropic response: ± 0.5 dB @ 50Hz

GENERAL CHARACTERISTICS

Recommended calibration interval: 24 months

Operating temperature: -10°C ÷ 50°C

Size: 365 x 120 Ø (mm)

Weight: 135 g
