Microchip Technology WINCS02IC-I/ZZX WiFi Modules Wi-Fi Network Controller SoC, 802.11 b/g/n

Security: WPA, WPA2, WPA3

Frequency: 2.5 GHz

Dimensions: 21.7 mm x 17.3 mm x 2.1 mm

Output Power: 20 dBm

Interface Type: SPI

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 3 V

Antenna Connector Type: U.FL

Operating Supply Voltage: 3 V to 3.6 V

Protocol - WiFi - 802.11: 802.11 b/g/n

Supply Current Receiving: 94 mA

Supply Current Transmitting: 289 mA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - Bluetooth, BLE - 802.15.1: Bluetooth
