Microchip Technology TC8220K6-G MOSFET Small Signals 2PR N- & PCH ENHANCE MODE MOSFET

Fall Time: 15 ns, 15 ns

Rise Time: 15 ns, 15 ns

Technology: Si

Unit Weight: 41.400 mg

Channel Mode: Enhancement

Configuration: Quad

Mounting Style: SMD/SMT

Transistor Type: 2 N-Channel, 2 P-Channel

Moisture Sensitive: Yes

Number of Channels: 4 Channel

Transistor Polarity: N-Channel, P-Channel

Typical Turn-On Delay Time: 10 ns, 10 ns

Typical Turn-Off Delay Time: 20 ns, 20 ns

Id - Continuous Drain Current: 2.3 A

Maximum Operating Temperature: + 150 C

Minimum Operating Temperature: - 55 C

Forward Transconductance - Min: 400 mS, 400 mS

Rds On - Drain-Source Resistance: 6 Ohms, 7 Ohms

Vds - Drain-Source Breakdown Voltage: 200 V

Vgs th - Gate-Source Threshold Voltage: 1 V
