Microchip Technology MCP112-475E/TO Voltage Detector 1uA Sup P-P Act Low

Width: 3.62 mm

Height: 4.62 mm

Length: 5.21 mm (Max)

Output Type: Active Low, Push-Pull

Unit Weight: 453.600 mg

Manual Reset: No Manual Reset

Qualification: AEC-Q100

Mounting Style: Through Hole

Output Current: 10 mA

Watchdog Timers: No Watchdog

Threshold Voltage: 4.63 V

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 1 V

Overvoltage Threshold: 4.7 V

Undervoltage Threshold: 4.561 V

Battery Backup Switching: No Backup

Operating Supply Current: 1.75 uA

Number of Inputs Monitored: 1 Input

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
