Microchip Technology LE50-28-28S-A-T Isolated LEO Space Grade Rad Tolerant DC-DC Power Converter

Width: 52.07 mm (2.05 in)

Height: 12.7 mm (0.5 in)

Length: 77.47 mm (3.05 in)

Output Power: 50 W

Mounting Style: Through Hole

Isolation Voltage: 100 V

Number of Outputs: 1 Output

Input Voltage - Max: 38 V

Input Voltage - Min: 22 V

Input Voltage, Nominal: 28 V

Output Current-Channel 1: 1.8 A

Output Voltage-Channel 1: 28 V

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 55 C
