Microchip Technology BM78SPPS5MC2-0006AA Bluetooth Modules Bluetooth 5 Dual Mode Module - Shielded FW 1.38

Antenna: Internal Antenna

Protocol: BLE, Bluetooth 5.0, BR/EDR

Frequency: 2.44 GHz

Shielding: Unshielded

Output Power: 1.5 dBm

Interface Type: UART, I2C

Mounting Style: SMD/SMT

Frequency Range: 2.402 GHz to 2.48 GHz

Protocol - Sub GHz: ISM

Receiver Sensitivity: - 90 dBm, - 92 dBm

Supply Voltage - Max: 4.2 V

Supply Voltage - Min: 3.3 V

Operating Supply Voltage: 3.8 V

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 20 C

Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
