Microchip Technology AT32UC3C164C-AUT 32-bit Microcontrollers - MCU UC3C 64K FLASH 16K SRAM

Core: AVR

Width: 14.1 mm

Height: 1.05 mm

Length: 14.1 mm

Unit Weight: 657 mg

Data RAM Size: 16 kB

ADC Resolution: 12 bit

Data Bus Width: 32 bit

Interface Type: CAN/Ethernet/I2S/SPI/TWI/USART/USB

Mounting Style: SMD/SMT

Number of I/Os: 81 I/O

Processor Series: AT32UC3C

Moisture Sensitive: Yes

Program Memory Size: 64 kB

Program Memory Type: Flash

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 3 V

Maximum Clock Frequency: 66 MHz

Number of Timers/Counters: 7 Timer

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
