Mettler Toledo 30803902 pH Sensor InPro3252i/SG/225

pH Range: 1 – 11

Model Family: InPro3250(i)

Sensor Length: 225 mm

Shaft Material: Glass

Cable Connector: K8S

Reference System: Pre-pressurized liquid electrolyte, ceramic diaphragm, Argenthal cartridge with silver-ion trap

Process Connection: Pg 13.5 Thread

Temperature Sensor: Digital

Measurement Parameter: ORP/Redox pH

pH Sensing Technology: Hydrofluoric Acid Resistant Glass Membrane (HF)

Refillable Electrolyte: No

ISM (Digital) or Analog: ISM (Digital)

Certificates & Approvals: ATEX/IECEx: Ex ia IIC T6/T5/T4/T3 Ga/Gb CE FM: IS Cl. I, II, III, Div 1, GR ABCDEFG/T6 METTLER TOLEDO Quality Certificate PED

Clean-In-Place Resistant: No

Hazardous Area Approvals: Yes

Operating Pressure (Bar): 0 to 4 barg

Operating Pressure (PSI): 0 to 58 psig

Primary Media/Application: Chemical Processes

Sterilizable/Autoclavable: No

Solution Ground/Redox Metal: Platinum

Operating Temperature (Celsius): 0 °C - 80 °C

Operating Temperature (Fahrenheit): 32 °F - 176 °F

Hygienic/Biocompatibility Approvals: No
