Weight: 83 lb (37 kg)
Detector: DTGS SE MCT
Software: iC IR iC Process
For Use In: Lab, Pilot Plant, or Production
Resolution: 4 cm -1 maximum
Communication: Ethernet TCP/IP
Probe pH Range: 1 – 14 (Diamond) 1 – 9 (Silicon)
Wetted Materials: Alloy C-22 Diamond or Silicon Gold
Protection Rating: IP54
Purge Requirement: Yes
Dimensions (HxWxD): 523 mm x 457 mm x 310 mm
Probe Optical Window: 2500 – 650 cm-1 maximum (Fiber Probe) 4000 – 650 cm-1 (Sentinel)
Safety Certification: Area Classification – NON-HAZARDOUS, MET Mark E112462, UL61010-1 & CSA C22.2 No. 61010-1
Operating Range (Temp.): 32 °F – 95 °F (0 °C – 35 °C)
Probe Pressure (Maximum): 107bar (Sentinel) 69bar (6.3 & 9.5mm Fiber Probe)
Optical Range (Base Unit): 4000 – 650 cm-1
Probe Temperature (Maximum): 180°C (Fiber Probe) 200°C (Sentinel)
