Meinsberg TM 40/Set PH, ORP, ISE, Temp Meter (0~14PH)

Measuring range pH 0 ... 14; - 1999 ... 1999 mV; temperature:- 10 ... 100 °C; ISE: 0 ... 30000 ppm

Resolution 0.01 pH; 1 mV; 0.1 °C
Temperature compensation automatic with Pt 1000 or fixed temperature
Display graphic LCD, 128 x 64 pixel, backlighted
Interface USB, isolated
Ambient temperature -10 ... 55 °C
Connectors connector BK for sensor, 4-pole USB interface socket
Housing ABS, IP 65
Dimensions 200 x 95 x 40 mm (WHD)
Weight 290 g incl. batteries (3 x AA, IEC R6, LR6, 1.5 V)
EMC acc. EN 61326 class B
recommended pH electrode EGA 142/TM 40 with integrated temperature sensor, plastic body Ø 12 mm,
gel electrolyte, ceramic diaphragm, 1 m fixed cable with 6-pol. connector BK
Delivery volume TM 40/Set Case with meter TM 40, pH combination electrode EGA 142/TM 40 with
integrated temperature sensor, 1 x 50 ml storage solution KCl 3 mol/l, 3 x 50 ml buffer solution
pH 4.01, 6.86 and 9.18 (25 °C)
