MEGGER MIT300 Insulation and Continuity Testers (500 V, 250 V (DC), 10 kΩ - 999 MΩ)

Insulation ranges

Nominal Test Voltage: 500 V, 250 V (DC)

Measuring Range: 10 kΩ - 999 MΩ on all ranges

Short Circuit Current: 1.5 mA nominal

Test Current on Load 1 mA at min. pass values of insulation (as specified in BS7671,HD 384 and IEC 364)

Accuracy (at 20 °C): ±3%, ±2 digits up to 10 MΩ, ±5% up to 100 MΩ, ±30% up to full scale

Continuity ranges

Measuring Range: 0,01 Ω - 99,9 Ω (0 -50 Ω on analogue scale)

Open Circuit Voltage: 5 V ±1 V

Short Circuit Current: 205 mA +10 mA –5 mA

Accuracy (at 20 °C): ±3% ±2 digits

Measuring range: 0 - 2/20/200/2 kΩ

Open circuit voltage: 1.5 V +/-0.5 V

Zero Offset Adjust: 0 - 9 Ω

Continuity Buzzer:

Operates at <5 Ω

Response time <20 ms
