MaxLinear XR79115EL-F Non-Isolated / PoL 15A Power Module in 12x12x4mm package using Patented Emulated Current Mode COT control

Width: 12 mm (0.472 in)

Height: 4 mm (0.157 in)

Length: 12 mm (0.472 in)

Industry: Industrial

Dimensions: 12 mm x 12 mm x 4 mm

Unit Weight: 810 mg

Mounting Style: SMD/SMT

Number of Outputs: 1 Output

Moisture Sensitive: Yes

Input Voltage - Max: 22 V

Input Voltage - Min: 3 V

Input Voltage, Nominal: 5 V, 12 V, 19.6 V

Output Current-Channel 1: 15 A

Output Voltage-Channel 1: 600 mV to 5.5 V

Operating Temperature Range: - 40 C to + 125 C

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
