MATRIX MPS-3210 Single Channel DC Power Supply (32V, 10A, 320W)

Rated input voltage: AC220V/110V ± 10%

Rated output voltage: 0-32V

Rated output current: 0-10A

Rated output power: 320W

Load regulation: Voltage: <0.1% + 10mV, Current: <0.2% + 5mA

Line regulation: Voltage: <0.01% + 10mV, Current: <0.2% + 5mA

Setting accuracy: Voltage: ≤0.1% + 1 digit, Current: ≤0.2% + 5mA

Setting resolution: Voltage: 10mV, Current: 1mA

Readback accuracy: Voltage: ≤0.1% + 1 digit, Current: ≤0.2% + 5mA

Readback resolution: Voltage: 10mV, Current: 1mA

Ripple: Voltage: ≤10mVrms, Current: ≤5mArms

OVP: 0-32V ± 0.2% FS

Maximum voltage: 32V ± 0.2%

OCP: 0-10A ± 0.2% FS

Maximum current: 10A ± 0.2%

Operating environment: 0 ~ 40°C ≤ 80RH

Storage environment: -15 ~ 70°C ≤ 80RH

Instrument size (WxHxD): 115x96x261 mm

Net weight: 1.5 kg

Gross weight: 1.9 kg

Datasheet

Catalog

 • Voltage and current simultaneously display, double four-digit LED display

• High power up to 320W with small volume

• Smart fan, unique air duct design keeps normal temperature for long time full load working

• Five sets of storage functions, greatly conve- nient for users

• OVP/OCP setting function

• Encoder sets voltage and current

• Fast and longer life

• Output control function
