MATRIX MPS-3030P High-Power DC Power Supply (30V, 30A, 900W)

Input voltage: AC 220V/110V±10% 50Hz/60Hz

Rated output voltage: 0~30V

Rated output current: 0-30A

Rated output power: 900W

Load regulation:

Voltage: ≤ 0.02% + 15mV

Current: ≤ 0.2% + 10mA

Line regulation:

Voltage: ≤ 0.02% + 15mV

Current: ≤ 0.2% + 10mA

Set resolution:

Voltage: 1mV

Current: 1mA

Setting accuracy:

Voltage: ≤ 0.01% + 10mV

Current: ≤ 0.1% + 5mA

Readback resolution:

Voltage: 1mV

Current: 1mA

Readback accuracy:

Voltage: ≤ 0.01% + 10mV

Current: ≤ 0.1% + 5mA

Ripple and noise:

Voltage: ≤ 10mV(rms)

Current: ≤ 10mA(rms)

Working environment: 0 to 40°C ≤ 80% R.H

Dimension (WxHxD): 480x142x370 cm

Weight: 22 kg
