MATRIX MPS-3010H-3 High Precision Triple-channel Linear DC Power Supply (30V, 10A, 3 channels)

Rated output:

Voltage: 0-30V (CH1, CH2), 5V (CH3)

Current: 0-10A (CH1, CH2), 3A (CH3)

Load regulation:

Voltage: ≤0.01%+8mV (CH1, CH2), ≤15mV (CH3)

Current: ≤0.1%+5mA (CH1, CH2)

Power regulation

Voltage: ≤0.01%+8mV (CH1, CH2)

Current: ≤0.1%+5mA (CH1, CH2)

Set resolution:

Voltage: 10mV (CH1, CH2)

Current: 1mA (CH1, CH2)

Readback resolution:

Voltage: 10mV (CH1, CH2)

Current: 1mA (CH1, CH2)

Set value accuracy:

Voltage: ≤0.03%+10mV (CH1, CH2)

Current: ≤0.1%+5mA (CH1, CH2)

Readback accuracy:

Voltage: ≤0.03%+10mV (CH1, CH2)

Current: ≤0.1%+5mA (CH1, CH2)

Parallel mode:

Power effect: ≤0.02%+8mV (CH1, CH2)

Load effect: ≤0.02%+8mV (CH1, CH2)

Serial mode:

Power effect: ≤0.01%+8mV (CH1, CH2)

Load effect: ≤0.01%+8mV (CH1, CH2)

Ripple and noise:

Voltage: ≤2mV(rms) (CH1, CH2, CH3)

Current: ≤5mA(rms) (CH1, CH2, CH3)

Working temperature: 0~40°C, ≤80%RH

Size (mm): 250*150*330

Weight (kg): 12
