MATRIX MPS-203 Single Channel DC Power Supply (150V, 2A, 300W)

Rated input voltage: AC220V/110V±10%

Rated output voltage: 0-150V

Rated output current: 0-2A

Rated output power: 300W

Load regulation rate: Voltage ≤0.02%+5mV, Current ≤0.02%+5mA

Line regulation rate: Voltage ≤0.02%+5mV, Current ≤0.02%+5mA

Setting resolution: Voltage 1mV, Current 0.1mA

Read back resolution: Voltage 1mV, Current 0.1mA

Setting accuracy (25℃±5°C): Voltage ≤0.1%+8mV, Current ≤0.2%+2mA

Read back accuracy (25℃±5°C): Voltage ≤0.1%+8mV, Current ≤0.2%+2mA

Ripple and noise (25℃±5℃): Voltage <10mVms, Current <3mArms

Temperature coefficient

Operating: 0 to 40°C, ≤ 80R.H

Storage: -15 to 70°C ≤ 80R.H

Machine size(W*H*D): 111*170*250 mm

Net weight: 2KG

Datasheet

Catalogue

Features

• It can save the output status and value before the last shutdown

• The adjustable range of current and voltage can be set

• Voltage compensation function to ensure high accuracy

• Restore factory settings with one click

• List output editing function

• Nine sets of voltage and current storage function, convenient and quick

• Intelligent temperature control fan, extremely practical

• Adjustable screen brightness

Applications

Prouduction line work bench routine test

Lab and institute

Electronic repair

Automated equipment integration testing
